Camera Module
|
|
|
sensor
|
1/2.8″ progressive scan CMOS
： ， ；
|
： ，
|
|
Mini. Illumination
|
Color 0.005Lux @ (F1.65 AGC ON)
|
B/W
|
0.001Lux @(F1.65
|
AGC ON);0 Lux with IR
|
|
Image setting
|
Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, and AWB adjusted by client software/browser
|
|
Shutter Speed
|
1/1 s – 1/100,000 s
|
|
White Balance
|
Auto/Manual/Indoor/Outdoor
|
|
Gain
|
Auto/Manual
|
|
Day & Night
|
IR Cut filter
|
|
Privacy Mask
|
Not supported by ver5.01 and supported by ver5.10
|
|
3D DNR
|
Auto/Manual
|
|
Image Enhancement
|
HLC, BLC, DWDR
|
|
Picture overlay
|
Logo picture could be overlaid on video with 128x128pixels,24bits jpg format
|
|
Lens
|
|
Focus length
|
f=4.8-120mm lens,25x optical
|
|
Zoom Speed
|
Approx. 3.6s (optical zoom, wide-tele)
；
|
|
|
；
|
|
Field of View
|
Horizontal:57.6° to 2.5°(wide-tele) Vertical: 34.4° to 1.4°(wide-tele) Diagonal: 64.5° to 2.9°(wide-tele)
|
|
Working distance
|
wide: 1.0m ~ INF; tele: 1.5m ~ INF
|
|
Aperture Range
|
F1.65 ~ F3.8 (wide-tele)
|
|
PTZ
|
|
Pan Range
|
360°endless
|
|
Pan speed
|
Configurable, from 0.4~80°/s; Max Preset speed: 80°/s
|
|
Tilt Range
|
From -5° to 90°
|
|
Tilt Speed
|
Configurable, from 0.4°~ 80°/s, Max Preset speed: 80°/s
|
|
Proportional Zoom
|
Yes
|
|
Preset
|
360
|
|
Cruise
|
8 cruises, up to 16 presets for each cruises
|
|
Track
|
4 tracks, record time over 3 minutes for each track
|
|
Power off memory
|
Support
|
|
Action mode
|
Preset/Cruise/Trace/Auto Scan/Random Scan
|
|
3D Positioning
|
Support
|
|
PTZ Position Display
|
Support
|
|
Schedule Task
|
Preset/Cruise/Trace/Auto Scan/Random Scan /Dome reboot
|
|
IR
|
|
IR Distance
|
150m
|
|
Smart IR
|
Yes, support facial priority and CPL priority
|
|
Network
|
|
Max Resolution
|
1920x1080
|
|
Main stream
|
1920x1080 ,1280x720 25/30fps
|
|
Sub stream
|
25fps (1280 × 720, 704 × 576 , 352 × 288); 30fps (1280 × 720, 704 × 480, 352 × 240)
|
|
Third
|
Stream
|
25fps (704 × 576, 480 × 240, 352 × 288) ; 30fps (704 × 480, 480 × 240, 352 × 240)
|
|
SVC
|
Yes
|
|
Video compression
|
Smart H.265/H.264/MJPEG
|
|
Protocols
|
HTTP, HTTPS, Ipv4/Ipv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP,DHCP, PPPoE
|
|
Simultaneous live view
|
Up to 6 channels
|
|
User / Host
|
Up to 16 users, 3 levels: Administrator, Advanced User and Normal User
|
|
Security Measures
|
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering
|
